Energy Storage Inverter & Controller All-in-one
On-Grid & Off-Grid Energy Storage All-in-one Machine
Integrated with LiFePO4 battery and hybrid inverter, the system could be plugged directly with grid, loads, MPPT and diesel generator
Max. 16 stack
6 working modes can be set for different time period
Flexible expansion of energy storage battery with modular design
| Model | XSD220-50A | XSD220-100A | XSD384-100A | XSD480-100A | |
|---|---|---|---|---|---|
| Controller spec. | rated voltage(V) | 220 | 384 | 480 | |
| rated charging current(A) | 50 | 100 | 100 | 100 | |
| Max. input voltage from battery(V) | 300 | 550 | 600 | ||
| Max. Input solar voltage(V) | 500 | 850 | 900 | ||
| Max. Input solar power(W) | 11000 | 22000 | 38400 | 48000 | |
| charging mode | 1 | ||||
| battery float voltage (Vdc) | MPPT | ||||
| battery charging average voltage (Vdc) | 247 | 440 | 550 | ||
| self loss (mA) | <300 | ||||
| communication | RS485 | ||||
| rated efficiency | ≥95% | ||||
| protect degree | IP20 | ||||
| Working environment | working temperature | -20ºC~+50ºC | |||
| relative humidity | <90% No condensing | ||||
| Altitude | 4000m | ||||
| Pressure endurance insulation | 1500VAC, 1 minute | ||||
| Noise (1 meter) | ≤50dB | ||||
| Protection function | Protection for input connecting contrary, input short of voltage, output over load, output short circuit and over heat. | ||||
| protect breaker | need extra input and output breaker | ||||
| dimension (W*L*H) mm | 482*450*222 (5U) | ||||
ESS SERIES
Integrates inverter, energy management module, UPS function, voltage stabilizer, surge protection, charging module, and MPPT solar charge controller.
Each layer can contain 2 x 3U/4U LiFePo4 batteries. For example, a single package of 5120Wh x 2 = 10240Wh. Supports free extension and combination.
Stationary type & Movable type with 360° trundles.
