DC1000V 30A Y4 Solar Connectors Kit Y Branch Parallel PV Adapter Cable Plug Male/Female Power Solar Panel Copper for MC4

1 / 5

DC1000V 30A Y4 Solar Connectors Kit Y Branch Parallel PV Adapter Cable Plug Male/Female Power Solar Panel Copper for MC4

Send Inquiry

Product Description

Specification

Locking system	Snap-in
Ambient temperature range	-40°C ~ +90°C (IEC) / -40°C ~ +75°C (UL)
Upper limiting temperature	+105°C (IEC)
Gender	MALE/FEMALE
Rated voltage	1000V DC
Rated Current	30A
Insulation material	PC/PA
IP level	IP67
Test voltage	6kV (50Hz, 1 min.)
Connector system	Φ4mm; Φ6mm

Selling Point

Unique Y Branch Parallel PV Adapter Cable Design

Features a distinct Y branch design, allowing for versatile and efficient use in parallel connection of solar panels, making it ideal for various solar projects.

Customizable Length

Available in custom lengths, catering to the diverse needs and requirements of users, ensuring optimal placement and flexibility in solar installations.

High Current Rating

Boasts a reliable rated current capacity, capable of handling substantial electrical loads, providing reliable power transmission and ensuring optimal performance of solar panel systems.

Durable and Weather-resistant Materials

Constructed with a sturdy, IP67-rated plastic housing and copper contact material. Designed to withstand harsh outdoor conditions, ensuring long-lasting durability and reliability in various environments.

Secure and Stable Connections

The 1P solar connector shape ensures a secure and stable connection, minimizing the risk of disconnections or loose connections during solar panel usage for enhanced operational safety and uninterrupted power supply.

FAQ

Q1: How is product quality guaranteed?

We guarantee quality by always providing a pre-production sample before mass production and conducting a final Inspection before shipment.

Q2: What types of electrical products can you purchase from us?

You can buy Power equipment, Low voltage electrical items, Electrical complete sets, Voltage protectors, and Lightning protection devices.

Q3: What is the rated voltage and current capacity for these solar connectors?

The rated voltage is 1000V DC, and the rated current capacity is up to 30A.

Q4: What materials are used for the connector system insulation?

The insulation material utilized in the connector system is high-quality PC/PA.

Q5: What are the operational temperature limits and IP ratings of the product?

The ambient temperature range is -40°C to +90°C (IEC) / -40°C to +75°C (UL) with an upper limiting temperature of +105°C (IEC). The connector boasts a weatherproof IP67 protection rating.

Q6: What connector system sizes and locking systems are supported?

The connector system supports Φ4mm and Φ6mm sizes, utilizing a secure snap-in locking system to ensure connection stability.

Product Detail

DC1000V 30A Y4 Solar Connectors Kit Y Branch Parallel PV Adapter Cable Plug Male/Female Power Solar Panel Copper for MC4

Product Description
