| Basic Information | Data |
|---|---|
| Cell Type | TOPCon cell 182*91 mm |
| Cell Arrangement | 144 pcs (12*12) |
| Module Size | 2260*1219*3 mm |
| Module Weight | 9.1KG |
| Junction Box | Enclosure rating IP68 |
| Output Cable | 4mm², 500mm cable net length (customizable) |
| Connector Registration | MC4 compatibility |
| Frame | N/A |
| Front Static Load (Snow Pressure) | 2400Pa |
| Rear Static Load (Wind Pressure) | N/A |
| Parameter | Crystalline Silicon | ASP-S2-80 | ASP-S2-85 | ASP-54-85 | Notes |
|---|---|---|---|---|---|
| Basic Information | |||||
| Material | Crystalline Silicon | Thin Film | Thin Film | Thin Film | |
| Dimensions (L×W×D) | 2260×1219×3mm | 1200×600×6.8mm | 1200×600×6.8mm | 1200×600×6.8mm | |
| Weight | - | 11.8kg | 11.8kg | 12.0kg | |
| Electrical Characteristics | |||||
| Nominal Power (Pm) | 580W | 80W | 85W | 85W | |
| Open Circuit Voltage (Voc) | 53.03V | 58.8V | 60.2V | 29.2V | |
| Short Circuit Current (Isc) | 13.86A | 1.90A | 1.97A | 4.19A | |
| Voltage at Pmax (Vm) | 44.19V | 47.4V | 48.3V | 23.0V | |
| Current at Pmax (Im) | 13.13A | 1.68A | 1.76A | 3.71A | |
| Max System Voltage | DC 1000/1500V (IEC) | - | - | - | |
| Max Fuse Current | 25A | - | - | - | |
| Temperature Coefficients | |||||
| Power (%/°C) | -0.26 | -0.214 | -0.214 | -0.214 | Negative = power decreases with heat |
| Voltage (%/°C) | -0.24 | -0.321 | -0.321 | -0.321 | |
| Current (%/°C) | +0.04 | +0.060 | +0.060 | +0.060 | Positive = current increases slightly |
| Warranty & Certifications | |||||
| Power Output Guarantee | - | 90% (10y), 80% (25y) | Same | Same | |
| Materials/Workmanship Warranty | - | 10 years | 10 years | 10 years | |
| Other | |||||
| Applications | PV Venues, Greenhouses, etc. | - | - | - | |
| Transport Package | Wooden Box | - | - | - |
| Parameter | ASP-S1-100 | ASP-S1-105 | ASP-S1-110 | ASP-S1-115 | ASP-S1-120 | ASP-S4-85 | Notes |
|---|---|---|---|---|---|---|---|
| Nominal Power (Pm) | 100W | 105W | 110W | 115W | 120W | 85W | STC Conditions |
| Open Circuit Voltage (Voc) | 123.5V | 124.0V | 176.84V | 180.49V | 181.00V | 29.2V | |
| Short Circuit Current (Isc) | 1.24A | 1.28A | 0.90A | 0.918A | 0.98A | 4.19A | |
| Voltage at Pmax (Vm) | 91.7V | 92.9V | 138.0V | 138.18V | 138.62V | 23V | Maximum Power Point |
| Current at Pmax (Im) | 1.09A | 1.13A | 0.80A | 0.834A | 0.87A | 3.71A | |
| Dimensions (L×W×D) | 1200×600×6.8mm | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | To be specified | All models unless noted |
| Weight | 12kg | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | To be specified | |
| Temperature Coefficients | |||||||
| - Power (%/°C) | -0.214 | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | To be specified | Negative = power decreases with heat |
| - Voltage (%/°C) | -0.321 | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | To be specified | |
| - Current (%/°C) | +0.060 | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | *Same as S1-100* | To be specified | Positive = current increases slightly with heat |
| Warranty | 10-year material/workmanship 25-year power output |
Applies to all models | |||||
| Certifications | 1500V system certified (IEC/UL) | Applies to all models |
| Transportation | Platform Lorry | Platform Lorry | Container |
|---|---|---|---|
| Size | 13m | 17.5m | 40 degree |
| Pallet | 22 | 28 | / |
| Piece/Pallet | 45 | 45 | / |
| Total Pieces | 990 | 1260 | / |
Q1: How can I get a quotation from you?
A1: You can leave us a message, and we will reply to every message in time. Or we may communicate online via Trade Manager.
Q2: Can I get samples before making an order?
A2: Yes, of course. Usually, our samples are free. We can produce items based on your samples or technical drawings, and build the necessary molds and fixtures.
Q3: How can you guarantee the quality of what I receive?
A3: We maintain rigorous quality control standards and competitive prices to ensure our customers benefit. We respect every customer and sincerely conduct business and build relationships with them, regardless of where they come from.
Q4: How much will the transportation freight cost?
A4: The freight charge depends on the package weight, dimensions, delivery address, and the selected shipping method (e.g., sea, air, or express delivery). We will assist you in choosing the most cost-effective and secure transport method.
Q5: What is the standard warranty period for these photovoltaic modules?
A5: Standard terms offer a 10-year materials/workmanship warranty and a 25-year power output guarantee, ensuring reliable long-term performance.
Q6: Can the output cable length of the modules be customized?
A6: Yes, while the standard cable net length is 500mm (4mm²), the cable length can be fully customized according to your specific project needs.
